TMC Compressors (TMC) has launched a range of marine compressors for use in combination with air lubrication systems – known in the shipping industry as “ALS” – to help ships further reduce fuel consumption and emissions to air.
What exactly is Air Lubrication Systsems (ALS)?
In ship resistance, the three main components are form resistance, wave resistance and frictional resistance. The form resistance is decided by the shape of the vessel and its hull, while the wave resistance is defined by size and direction of the ocean’s waves.
An air lubrication system addresses the frictional resistance between a vessel’s hull as it sails trough seawater.
Skin frictional resistance depends on the wetted surface area of a ship. Air lubrication technology can reduce this frictional drag for vessels, since the technology does not introduce major changes in hull form and the air injection rate can be adjusted. Without major changes in hull form or change in operational speed, the form and wave resistance are mostly fixed and only frictional drag is reduced.
Reducing resistance between the ship’s hull and seawater by using air bubbles
Simply explained, air lubrication system is a method used to reduce the resistance between the ship’s hull and seawater by using air bubbles. The air bubble distribution across the hull’s surface reduces the resistance working on the ship’s hull, thereby allowing the vessel to sail through seawater with lower resistance.
There are several different types of air lubrication system methods, including air film, air cavity and microbubbles. TMC delivers marine compressors to air lubrication systems that are based on the microbubble method.
TMC delivers the Microbubble method
The microbubble method is gaining popularity since it can be used on existing hulls. Small bubbles are injected into the water near the ship’s hull through several nozzles, which reduce the resistance between the hull and the seawater.
The exact process in which friction decreases in the mixture of air and water is dependent on many factors such as size of the bubbles and where they are injected. However, the bubbles need to be as close as possible to the solid surface of the hull. The biggest challenge is to keep the bubbles inside the so-called boundary layer.
The bubbles that are washed away from the area near the hull-wall lose their effect. Therefore, drag reduction only works in a section close to the air outlet. Several air injectors can be placed separately to continuously reduce the drag along the hull wall. The size of the microbubbles is also important since big bubbles cannot move inside the boundary layer and the buoyancy force influences their motion.
Advantages of the microbubble method is that is has the possibility of retrofitting to existing hulls, plus that it has minimum effect on vessel manoeuvrability.
Moreover, installing an air lubrication system can reduce the vessel’s net energy consumption considerably, with associated reduction of harmful emissions to air. In order to be economically viable, this energy saving needs to give a larger cost saving than the capex and opex the air lubrication system is adding.
Reduction of emission and operating costs
In conclusion, with the right ship hull design, the air lubrication system can generate substantial reductions of both fuel and CO2 emissions, with an associated decrease of the vessel’s operating costs. TMC is therefore proud to offer a compressed air product that can help ALS become more mainstream in the shipping and offshore industries.
